78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

Ask Latest Price
Video Channel
Brand Name :BYF
Model Number :90×16-9
Certification :ISO9001:2015
Place of Origin :China
MOQ :Negotiable
Price :Negotiable
Payment Terms :L/C, T/T, Western Union, , Cash
Supply Ability :10000 Ton/Tons Per Month
Delivery Time :20-25 Days
Packaging Details :By The Requirement Of Customer
Material :60Si2Mn&SUP9
Size :90×16-9
Color :Black Or As Required
Surface Treatment :E-Coating/Anti-Rusty Oil≥240 Hours Salty Spray Test
Weight :78.00 KG
Fatigue Testing :≥180K Cycles
Shoot Peening :≥0.18C
Hardness :40-47HRC
OEM :Customized Design And Producing In Different Level
Logo :Customer Customization
Loading Port :Qingdao Port Or As Required
more
Contact Now

Add to Cart

Find Similar Videos
2080.06520 Parabolic Leaf Spring 00:39
2080.06520 Parabolic Leaf Spring
BYF-10T Fasten Strap The Ultimate Trailer Spare Part for Heavy Duty Lashing Needs 00:30
BYF-10T Fasten Strap The Ultimate Trailer Spare Part for Heavy Duty Lashing Needs
Semi Trailer OEM EATON 819708 American Brake Shoe 4726 ES-2 00:42
Semi Trailer OEM EATON 819708 American Brake Shoe 4726 ES-2
Heavy Duty Semi Trailer European Type Brake Shoe 61540 00:33
Heavy Duty Semi Trailer European Type Brake Shoe 61540
21222694 10 Teeth 72788 Automatic Trailer Slack Adjuster 00:33
21222694 10 Teeth 72788 Automatic Trailer Slack Adjuster
Black OEM MERITOR A-3222-J-2272 4718 QP Brake Shoe 00:36
Black OEM MERITOR A-3222-J-2272 4718 QP Brake Shoe
Trailer Parts MERITOR A-3222-K-2169 American Brake Shoe 4711 QP 00:41
Trailer Parts MERITOR A-3222-K-2169 American Brake Shoe 4711 QP
5.56 KG OEM 152.06.227 American Brake Shoe 4516 CA32 00:31
5.56 KG OEM 152.06.227 American Brake Shoe 4516 CA32
14mm Bushing 81506106264 Auto Slack Adjuster 80177 01:09
14mm Bushing 81506106264 Auto Slack Adjuster 80177
Haldex 1 Hole 10 Teeth Automatic Slack Adjuster 72917 | OEM 21222924(ROR) | Casting 2760 For Heavy Duty Truck 00:34
Haldex 1 Hole 10 Teeth Automatic Slack Adjuster 72917 | OEM 21222924(ROR) | Casting 2760 For Heavy Duty Truck
View Product Description

Fuwa Type Leaf Spring 90×16-9 Semi Trailer | For Heavy Duty Trailer | SUP9 & 60Si2Mn | Fatigue Testing ≥180K Cycles

LEAF SPRING 90×16-9/ 60Si2Mn & SUP9

What's advantages of our leaf spring?

1. OEM qualtity control to make sure that our leaf spring could long times service. All of our products is official process without any process deleting.

2. Fatigue testing pass through al the international standard, according to our customer requirement.

3. Especiall the torlerance controll of key dimension is 50% higher than other factories.

4. Our engineers got more than 20 years experience in doing this industry. We can slove all problem you met before.

5. Strictly quality control. Any complain from you will be quickly treated, and the solution would be given to you inside of 3 days.

6. Provide customers with any type of customized production.


How long would be needed to your order?

Our capacity of production one simple type leaf spring is 600 Tons/8 hours.

Technical Standard

1. Single piece leaf spring hardness need to be HB378-445 after heat treatment;

2. Overheating, overburning, cracking, folding, bruising and other defects are not allowed on surface;

3. Each sinlgle leaf spring need to do stress shot peening treatmnet;

4. After the spring assembling, the center bolt must be punched and riveted;

5. Bolt mechanical performance level: 8.8-GB3098.1-2000;

6. The surface defects of bolts shall be implemented according to GB5779.1-2000;

7. Tolerance of bolts is according to GB3103.1-1982 Grade B product ;

8. The spring assembly is painted with black paint or as requested, according to QC / T484-TQ9;

9. Other technical requirements shall be implemented according to GB / 19844-2005.

Product Details

Size 90×16-9
Material 60Si2Mn&SUP9
Surface Treatment E-Coating/Anti-Rusty Oil≥240 Hours Salty Spray Test
Fatigue Testing ≥180K Cycles
Hardness 40-47HRC
Weight 78.00 KG
Color Black Or As Required
Shoot Peening ≥0.18C
OEM Customized Design And Producing In Different Level
Logo Customer Customization
Loading Port Qingdao Port Or As Required

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

Drawing Details

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

No. Specifications Straighten
length (mm)
Distance from front section to center hole (mm)
1 16×9 1163 581.5
2 16×9 1163 581.5
3 16×9 1163 581.5
4 16×9 1195 581.5
5 16×9 850 425
6 16×9 700 350
7 16×9 550 275
8 16×9 400 200
9 16×9 250 125

Production & Packing

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring 78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring 78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

78.00kg 60Si2Mn SUP9 90×16-9 Fuwa Type Leaf Spring

Excellent Pre-sale Service

1. According to your specification request, provide the best price for you.

2. After you confirmed the specification and price, our engineers will draw a Official Drawing for you confirm.

3. After our Finance Department confirmed your deposit or Irrevocable L/C, we will start manufacture the products for you.

4. Update the progress of production to you in time, to help you know your order details progress.

5. After the product manufacture finished, if you need, we will arrange shipping for you.

With our professional skill, you just need to pick your products up at the destination place, and don’t need to worry about the shipping at all.
